Copper wound transformer coil with the following advantages:
1, insulation material and the copper conductor close to the expansion coefficient
2, copper conductivity, thermal conductivity, good heat dissipation
3, short high intensity (high melting point of copper)
4, added to the stress of insulation material on the minimum (pure copper is easy bending)
5, high utilization ratio
6, easy welding
7, winding coil, the winding insulation and copper at the same time easy to operate, less time, high efficiency, low labor costs
Material Report (C1100)
Ingredients:
|
Cu
|
P
|
O2(ppm)
|
|
≥99.90
|
--
|
200--450
|
Physical characteristics:
|
Melting point ℃ (liquid)
|
1083
|
|
Melting point ℃ (solid phase)
|
1065
|
|
Proportion
|
8.94
|
|
Coefficient of thermal expansion 10-6/℃
|
17.7
|
|
Thermal conductivity cal/cm2/cm/sec/℃
|
0.935
|
|
Electrical conductivity LACS%
|
99
|
|
Longitudinal elasticity kgf/mm2
|
12000
|
Mechanical Characteristics:
|
Do quality
|
GS(μ)
|
HV
|
TS(kg/mm2)
|
EL%
|
Notes
|
|
O
|
15-30
|
Under 60
|
Above 20
|
Above 35
|
|
|
H/4
|
|
60-80
|
20-26
|
Above 25
|
|
|
H/2
|
|
80-100
|
26-32
|
Above 15
|
|
|
H
|
|
100-130
|
Above 30
|
Above 5
|
|
Electronic Transformer specification sheet with copper foil
|
0.025mm
|
0.180mm
|
0.500mm
|
1.00mm
|
1.80mm
|
|
0.035mm
|
0.200mm
|
0.550mm
|
1.10mm
|
1.90mm
|
|
0.050mm
|
0.250mm
|
0.600mm
|
1.20mm
|
2.00mm
|
|
0.075mm
|
0.300mm
|
0.650mm
|
1.30mm
|
2.10mm
|
|
0.080mm
|
0.350mm
|
0.700mm
|
1.40mm
|
2.20mm
|
|
0.100mm
|
0.400mm
|
0.750mm
|
1.50mm
|
2.30mm
|
|
0.125mm
|
0.400mm
|
0.800mm
|
1.60mm
|
2.40mm
|
|
0.150mm
|
0.450mm
|
0.900mm
|
1.70mm
|
2.50mm
|
Width up to 2--1040mm
Special black chrome solar copper Specifications
|
0.12*100*1840mm
|
0.15*125*1840mm
|
0.15*140*1840mm
|
0.15*250*1840mm
|
|
|
|
|
|
|
|
Tolerance standard table
Bare copper foil (thickness tolerance)
|
Copper foil thickness
|
Tolerance
|
Copper foil thickness
|
Tolerance
|
Notes
|
|
<0.10mm
|
+0.005/-0.005
|
1.60-2.00mm
|
+0.03/-0.03
|
|
|
0.10-0.18mm
|
+0.01/-0.01
|
2.10-2.50mm
|
+0.035/-0.035
|
|
|
0.20-0.38mm
|
+0.015/-0.015
|
2.60-4.00mm
|
+0.04/-0.04
|
|
|
0.40-0.80mm
|
+0.02/-0.02
|
|
|
|
|
0.90-1.50mm
|
+0.025/-0.025
|
|
|
|
Bare copper plate (width tolerance)
|
Foil width
|
Tolerance
|
Copper plate width
|
Tolerance
|
Notes
|
|
2-305mm
|
+0.08/-0.08
|
305-600mm
|
+1.0/-1.0
|
|
Gum foil (width of the tolerance
|
Foil width
|
Tolerance
|
Foil width
|
Tolerance
|
Notes
|
|
<15mm
|
+0.50
|
>15mm
|
+1.0
|
|
Tape Anti-package (width tolerance)
|
Anti-packet width tape
|
Tolerance
|
Anti-packet width tape
|
Tolerance
|
Notes
|
|
Standards
|
+0.5/-0.5
|
|
|
According to the standard
|
|
Tightening the requirements
|
+0.3/-0.3
|
|
|
According to customer orders
|
|
Special requirements
|
+0.2/-0.2
|
|
|
According to customer orders
|
|
| |
|
 |
